ESP-U Round Diffuser

APPLICATION AREAS
This type of grille is used as both a supply and return air outlet in ventilation systems. It has a fixed, curved-blade design, making it suitable for horizontal air discharge. In applications where the Coanda effect is desired, it should be installed flush with the ceiling. In this configuration, circular air distribution is achieved. It is suitable for use in ceiling heights of up to 4 meters.

IMPORTANT NOTE
Orders must be placed by specifying the nominal size. (First, the nominal size suitable for the required airflow rate should be determined.)

FEATURES
Circular diffusers are manufactured using proprietary molds belonging to our company, produced from aluminum sheet by the spinning (forming) method. The diffusers are chemically cleaned and then coated with electrostatic powder paint. Standard dimensions are provided in the tables.

INSTALLATION MATERIALS, PACKAGING & TRANSPORTATION
Mounting screws are supplied with the grilles. Packaging is carried out using polyethylene film. Since the grilles are fragile and may deform, transportation must be handled with care.

The standard paint color is RAL 9010. Painting in all RAL colors is available upon request.
